Specification

Printing method | Direct thermal printing
Effective
printing width | 72mm or 48mm
Resolution | 203dpi
Printing speed |  250mm/s
Printing density | 576 dots/line or 384 dots/line
Character set | GB18030 (Simplified Chinese)
Print font | ASCII Font A：12×24
ASCII Font B：9×17
Chinese: 24×24
Character
per line | Font A-48 lines/Font B-64 lines
/ Chinese-24 lines
Paper specification
Paper width | 79.5±0.5mm
Paper roll
diameter | Φ80mm
Paper loading | Paper loading
Barcodes
Barcode type | UPCA / UPCE / EAN13 / EAN8 / CODE39
/ I25 / CodeBar / CODE128 / CODE93 / CODE11
/ MSI / QRCORE / PDF417
Reliability
Thermal
printing head | 150km
Auto cutter | 1.5 million cuts
Interface | L、L-P、UP、US、USE、USE-P、USE-PE、WU
Emulation | ESC/POS/OPOS
Driver | WIN2003 / WINXP / WIN7 / WIN8
/ WIN10 / LINUX / MAC
Power supply | DC 24V,2.5A
Cash drawer
Control | DC 24V，1A
Certificate | 3C、CE、FCCID 、BIS、ROHS、REACH
weight | 1.07kg
Dimension | (LxWxH) 195×145×147mm
Environment
temperature | working temperature: 0~45℃
Storage：-10~60℃
humidity | working temperature: 20-90%
Storage:10-90% paper excluded）
